Model S18

Productive. Valuable. Easy.

S18 Model Overview

Designed with simplicity, durability, and serviceability in mind — the S18 remains the ideal entry-level, grass handling Walker Mower that is light-on-the-turf, productive, and versatile.

It features the patented Grass Handling System using a 12.5 inch, two-piece blower assembly with Thru-Shaft PTO providing powerful suction and leaving a clean, smooth cut. With thicker scroll and backplate, the two-piece blower is not only more durable, but repairs or replacement are now much easier.

Mower blades and powered attachments are now driven by an electric Ogura PTO clutch with Soft Start technology, simplifying maintenance and providing easy, worry-free operation of the PTO in any season.

Able to run 36 to 56 inch decks, the S18 is the perfect choice for residential properties, gated yards, and demanding customers.

Type: Collection
Power: 18 HP
Engine: Briggs & Stratton Vanguard
Ideal Application: Residential Properties, Small Commercial Properties
Key Attributes: Compact, Agile, Productive
Standard Options: 18 x 7.0-8 Turf Tire, Standard Seat

Decks:
Popular Add-ons:
Single-Stage Snowblower
48” Dozer Blade
Dethatcher

* MODELS MAY BE SHOWN WITH OPTIONAL EQUIPMENT. APPLICABLE FREIGHT, SETUP, AND TAXES NOT INCLUDED. ADDITIONAL DELIVERY FEES APPLY FOR US TERRITORIES AND STATES OUTSIDE OF THE CONTINENTAL US. OPTIONS AND ACCESSORIES EXTRA. PRICES SUBJECT TO CHANGE WITHOUT NOTICE. MSRP SHOWN IN US DOLLAR ARE FOR DOMESTIC USE ONLY. SEE LOCAL DEALER FOR COMPLETE PRICING AND AVAILABLE OFFERS.

s18-overview




Ready to try one for yourself?
Get a Demo

Features

Key Attributes - Compact

Compact

Get Into and Out of Tight Spots

Key Attributes - Agile

Agile

Be Responsive, Be Profitable

Key Attributes - Balance

Balance

Experience Proper Weight Distribution

S18 Comparison



  S18 C19 C19i
Engine Briggs Vanguard V-Twin Kohler CH620 Kohler ECH630
Fuel System Carb Carb EFI
Cooling System Air Air Air
Displacement 570 cc (34.8 cu. in.) 674 cc (41.1 cu. in.) 694 cc (42.4 cu. in.)
Max Power 18 HP @ 3600 RPM 19 HP @ 3600 RPM 19 HP @ 3600 RPM
Max Torque 29.2 ft-lbs 35 ft-lbs 34.2 ft-lbs
Fuel Capacity 4 gal (15.1 liter) 4 gal (15.1 liter) 4 gal (15.1 liter)
Grass Handling Collection Collection Collection
Seat Standard Seat Standard Seat Standard Seat
Tires 18 x 8.5-10 Turf Tire 18 x 8.50-10 Turf Tire 18 x 8.50-10 Turf Tire
Weight 675 lbs (306 kg)[1]
866 lbs (393 kg)[2]
762 lbs (346 kg)[1]
953 lbs (432 kg)[2]
760 lbs (345 kg)[1]
951 lbs (431 kg)[2]
Dimensions 46.5 in (118 cm)" H x 43.25 in (110 cm)" W x 89.25 in (226.5 cm)" L[2] 47.5 in (121 cm)" H x 43.25 in (110 cm)" W x 89.25 in (237 cm)" L[2] 47.5 in (121 cm)" H x 43.25 in (110 cm)" W x 89.25 in (237 cm)" L[2]

[1] Tractor only. [2] Tractor with C42 deck. [3] Tractor with M48 deck.

Own An S18

New Call-to-action
Request A Demo
Download Brochure
Download Brochure
New Call-to-action
Calculate Productivity Savings

Warranty

2YEARSentire tractor
2YEARSor 2000 hours on drive system*
3YEARSengine
LEARN MORE *Gear Axle Assembly, Hydrostatic Transmissions for C, D, T and Hydrostatic Transaxles for B, H, S, R and C23i

Video



Introduction (1:24)



In-Depth (5:18)



S18 Model Overview



S18 Release



Teaser (0:38)



Feature: Compact



Feature: Leaf Cleanup



Feature: Snow Removal



Inside the Grass Handling System

Specifications

Engine

Manufacturer: Briggs & Stratton Vanguard

Model: 356447-1338

Displacement: 570 cc (34.8 cu. in.)

Max Power: 18 HP @ 3600 RPM

Max Torque: 29.2 ft-lbs

Cooling System: Air

Fuel: Regular grade unleaded gasoline (87 octane minimum, 10% ethanol maximum)

Fuel Capacity: 4 gal (15.1 liter)

Electrical

Battery: 12V, 300CCA

Charging System: Flywheel Alternator

Charging Output: 16 Amp DC (Regulated)

Transmission

Manufacturer/Model: Dual, Independent Hydro-Gear® ZT3100 Integrated Transaxles

Steering: Hand Lever Control, Individual Wheel

Forward Speed Control: Precision Friction Lock Lever, Cruise Control, with Neutral-Park Position

Parking Brake: Internal Mechanical Cog Lock for each Transaxle (Single Lever Control)

Forward MPH (km/h): 0-7.4 (0-11.9) Infinitely Variable

Neutral: Transmission Release by Manual Dump Valve

Blade Drive

PTO Shaft: Quick Disconnect Splined Shaft with Two (2) High-Speed U-Joints

Blade Drive Clutch and Brake: Ogura Electric Clutch with Soft Start Engagement and Mechanical Brake [Stops Blades within Five (5) Seconds of Disengagement]

Grass Handling

Blower: 12.75 in. Diameter, Three-Blade Paddle Wheel, Integrated Thru-Shaft PTO

Max. Blower RPM: 2900 RPM

Grass Catcher Capacity: 65 Gal / 7.0 Bu / 246 L

Full Signal: Grass-Pak® full signal alerts operator when catcher box is full

Powerfil®: Oscillating Delivery Spout Driven by 12 Volt Electric Gearmotor Spreads Material throughout Interior of Catcher @ 35 Cycles/Min

Deck

Recommended Cut Width: 36 to 56 in. (91 or 142 cm) (Collection, SD, Mulch)

Cutting Height: 1 to 4 in (2.5 to 10 cm) or 1.5 to 4.5 in (4 to 11.5 cm) in 1/2 in (1 cm) Increments

Deck Suspension: Torsion-Flex Frame with Caster Wheels and Counterweight Springs

Tires

Drive: 18 x 7.00-8 (pneumatic 4-ply, standard) 18 x 8.5-10 (pneumatic, 4-ply, optional low-profile)

Tailwheel: 13 x 6.50-6 (pneumatic 4-ply)

Deck Caster: 8 x 3.00-4 (Foamed rubber standard, optional pneumatic)

Size & Weight

LENGTH

  • Tractor Only: 65 in (165 cm)
  • Tractor with C42 deck: 89.25 in (226.5 cm)
  • Tractor with C48 deck: 94 in (239 cm)
  • Tractor with deck tilted: 77 in (196 cm)
  • Tractor wheel base: 42.25 in (107 cm)

WIDTH

  • Tractor Only (Outside Tire): 38.5 in (98 cm) NOT narrow drive tires
  • Tractor with C42 deck: 43.25 in (110 cm)
  • Tractor with C48 deck: 49.25 in (125 cm)

HEIGHT

  • Tractor: 46.5 in (118 cm)

WEIGHT

  • Tractor Only: 675 lbs (306 kg)
  • Tractor with C42 deck: 866 lbs (393 kg)
  • Tractor with C48 deck: 898 lbs (407 kg)

Downloads

Manuals

Released Class Model Type Model S/N Range Manual P/N Download
04/23/2024 Model-S S18 Parts 181152 - AND ON 5000-81 PDF
04/11/2024 Model-S S18 Operator's 186174 - AND ON 5000-80 PDF
11/23/2022 Model-S S18 Parts 178948 - 181151 5000-72 PDF
11/23/2022 Model-S S18 Operator's 178948 - 186173 5000-71 PDF
04/04/2022 Model-S S18 Parts 175767 - 178947 5000-65 PDF
10/08/2021 Model-S S18 Parts 162840 - 175766 5000-63 PDF
10/08/2021 Model-S S14i Parts 165757 - AND ON 5000-64 PDF
10/04/2021 Model-S S18 Operator's 165345 - 178947 5000-62 PDF
10/07/2020 Model-S S14i Operator's 159072 - AND ON 5000-56 PDF
04/23/2020 Model-S S18 Operator's 158891 - 165344 5000-53 PDF
02/05/2020 Model-S S18 Parts 153873 - 162839 5000-51 PDF
12/16/2019 Model-S S14i Parts 154257 - 165756 5000-42 PDF
07/10/2019 Model-S S14i Operator's 154257 - 159071 5000-46 PDF
11/05/2018 Model-S S18 Operator's 154003 - 158890 5000-41 PDF
06/07/2018 Model-S S18 Parts 148901 - 153872 5000-40 PDF
12/06/2017 Model-S S14i Operator's 147007 - 154256 5000-37 PDF
12/06/2017 Model-S S14i Parts 147007 - 154256 5000-36 PDF
05/17/2017 Model-S S18 Operator's 143965 - 154002 5000-33 PDF
03/05/2017 Model-S S18 Parts 144715 - 148900 5000-32 PDF
05/05/2014 Model-S S14 Operator's 127922 - AND ON 5000-28 PDF
05/05/2014 Model-S S14 Parts 128442 - AND ON 5000-27 PDF
04/25/2014 Model-S MS Parts 117172 - 128441 5000-22 PDF
04/01/2005 Model-S MS Parts 78322 - 117171 5000-14 PDF
01/15/2005 Model-S MS Operator's 69735 - 127921 5000-16 PDF
03/02/2004 Model-S MS Parts 60136 - 78321 5000-12 PDF
10/01/2003 Model-S MS Operator's 57906 - 69734 5000-11 PDF
11/05/1997 Model-S MS Operator's 20381 - 57905 5000-1 PDF
10/01/1997 Model-S MS Parts 20381 - 60135 5000-2 PDF
07/01/1997 Model-S MS Operator's 00000 - 20380 5895 PDF
11/05/1991 Model-S MS Parts 00000 - 20380 5895-1 PDF
